Two cases of solitary fibrous tumor/hemangiopericytoma with different clinical features according to the World Health Organization classification: case report and review of the literature

Introduction

Solitary fibrous tumor (SFT) and hemangiopericytoma (HPC), which were previously treated as different types of tumors, have been defined as combined entities since the 2016 World Health Organization (WHO) reclassification, following the discovery of the NAB2/STAT6 fusion gene in both tumors. In the Central Nervous System (CNS), a hypocellular, collagenized tumor with a classic SFT phenotype is considered grade I, whereas more densely cellular tumors mostly corresponding to the HPC phenotype are classified as grade II or III (anaplastic) depending in mitotic count (<5 vs. >5 mitoses per 10 high-power fields) (1,2).

SFT/HPC in the spinal region is less frequently than that occurring in the intracranial region (3,4). The primary goal of treatment for spinal SFT/HPC is total removal of the tumor. The extent of surgical resection is thought to affect the patient's prognosis, and completely resected tumors have been reported to have a better prognosis (5,6); however, the factors that determine the surgical removal rate for spinal SFP/HPC remain unclear.

This case report presents two targeted cases of intradural extramedullary SFT/HPC at the craniocervical junction: WHO grade I tumor with no invasion into the spinal cord or vessels and WHO grade II tumor involving the vertebral artery. These histological diagnoses were confirmed by two pathologists. Since the craniovertebral junction is a complex area with vital neural and vascular structures, infiltration into surrounding tissues may reduce the rate of tumor removal. This study aimed to highlight the difference between the WHO grade of SFT/HPC at the craniocervical junction and the intraoperative findings that determine surgical difficulty. We present the following article in accordance with the CARE reporting checklist (available at https://dx.doi.org/10.21037/jss-21-83).

Case presentation

Case 1

A 75-year-old woman with past medical history of rheumatoid arthritis was referred to our hospital after a tumor was found by a magnetic resonance imaging (MRI) of the head due to headache. She had no other neurological symptoms. MRI of the cervical spine showed an intradural extramedullary tumor at the C1 to C2 levels. The spinal cord was markedly compressed and displaced to the contralateral side. The tumor was isointense on T2-weighted images and showed homogeneous enhancement after administration of gadolinium (Figure 1). Thus, the preoperative diagnosis was spinal meningioma.

Figure 1 Magnetic resonance imaging (MRI). (A) Preoperative sagittal T2 weighted MRI demonstrating isointensity of the lesion. (B) Preoperative sagittal T1 weighted MRI with contrast demonstrating homogeneous enhancement of the tumor, and (C) axial. (D) T2 weighted MR image demonstrating gross total removal of the tumor.

We performed C1-2 laminectomy. After cutting the dura with a microsurgical technique, an intradural extramedullary tumor mass was visualized on the right side of the spinal canal. The tumor was well circumscribed, smooth-marginated with dural attachment, and scarcely vascularized. The tumor did not adhere to the surrounding structures. Intraoperative frozen section analysis suggested a grade I meningioma. Total removal of the tumor was achieved, and according to the meningioma excision classification, it was Simpson grade II (Figure 2).

Figure 2 Intraoperative photographs of the tumor resection. (A) Following the dural opening, a mass lesion was visible on right lateral to the dura. (B) The tumor was completely resected.

Hematoxylin-eosin-stained sections revealed patternless architecture of a tumor composed of cells with bland ovoid-to-spindle-shaped nuclei and scant eosinophilic cytoplasm, and stromal collagen deposition. The mitotic figures were scant. Immunohistochemical studies showed that the tumor cells were positive for STAT6, CD 34. The Ki-67 labeling index was 1–3%. This revealed that the pathologic type was SFT/HPC, WHO grade I (Figure 3).

Figure 3 Histopathology of the resected mass. (A) Microscopic findings. Hematoxylin and eosin (H&E) stained section showed patternless architecture of a tumor composed of cells with bland ovoid-to-spindle-shaped nuclei and scant eosinophilic cytoplasm, and stromal collagen deposition. The tumor cells were positive for (B) CD34 and (C) STAT6. (D) The Ki-67 labeling index was 1–3%. Original magnifications ×200.

The patient’s postoperative course was uneventful. At 6-month follow-up, the patient showed no recurrence.

Case 2

A 68-year-old previously healthy woman presented with a 2-month history of numbness in the right upper limb. MRI of the spine revealed an intradural extramedullary tumor in the medulla to the C3 level. The tumor had a speckled high-signal area with a partial flow void on T2-weighted images and partially heterogeneous enhancement after administration of gadolinium. Preoperative left vertebral angiography showed that the posterior meningeal artery was the primary feeding vessel (Figure 4).

Figure 4 Magnetic resonance imaging (MRI) and angiography. (A) On preoperative sagittal T2 weighted MRI, the tumor demonstrated a speckled high-signal area with a partial flow void. (B) Preoperative sagittal T1 weighted MRI with contrast demonstrating partially heterogeneous enhancement of the tumor, (C) and axial. (D) Preoperative axial T2 weighted MRI demonstrate left vertebral artery (arrow) was passing through the tumor. (E) Preoperative frontal view of left vertebral artery angiography showed that the posterior meningeal artery (arrowhead) was the main feeding vessel, but it did not strongly feed the tumor. (F) Postoperative T2 weighted MRI showed that the tumor was almost entirely removed.

We performed suboccipital craniotomy and C1-3 laminectomy. After midline dural opening under a microscope, a solid tumor was found on the posterior medulla and spinal cord. The caudal part of the tumor was soft and there were no adhesions to the spinal cord, but the cranial part of the tumor was hemorrhagic and firmly adherent to the pia of the spinal cord and medulla, and involved the vertebral artery, the nerve roots of C1, C2, and lower cranial nerves. Intraoperative frozen section analysis suspected primitive neuroectodermal tumor (PNET), equivalent to grade IV. The tumor was removed in a piecemeal manner, and subtotal removal of the tumor was achieved (Figure 5).

Figure 5 Intraoperative photographs of the tumor resection. (A) Intraoperative photographs of the tumor resection. After dural opening, extramedullary tumors were identified in the medulla and posterior spinal cord. (B) In the area higher levels than C1, it was firmly adherent to the pia of the spinal cord and medulla. (C) The tumor was hemorrhagic and involved the vertebral artery (arrow). (D) Tumor has been almost completely removed.

Hematoxylin-eosin-stained sections revealed diffuse high cellularity with little intervening stroma. There was no necrosis, but scattered mitotic figures were observed. Immunohistochemical staining was positive for STAT6 and CD 34. The Ki-67 labeling index was 5%. Thus, the pathological diagnosis was SFT/HPC WHO grade II (Figure 6).

Figure 6 Histopathology of the resected mass. (A) Microscopic findings. Hematoxylin and eosin (H&E) stained section showed diffuse high cellularity with little intervening stroma. There was no necrosis. Mitotic figures were found sparingly. The tumor cells were positive for (B) CD34 and (C) STAT6. (D) The Ki-67 labeling index was 5%. Original magnifications ×200.

The postoperative course was uneventful. FDG-PET 1 month postoperatively showed no local recurrence or metastasis. Adjuvant radiotherapy was not performed. At 18 months of follow-up, MRI showed no tumor recurrence.

All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient for publication of this case report and accompanying images. A copy of the written consent is available for review by the editorial office of this journal.

Discussion

Previously different entities, SFTs and HPCs of the meninges were combined into a single category of fibroblastic type mesenchymal tumors according to the 2016 WHO classification because of the common NAB2-STAT6 fusion gene (1). SFT/HPC may be found in any soft tissue, but it is rarely found in the CNS, while tumors in the spinal cord are even more rare (3,4). The classical SFT subtype with low cell density, low nuclear fission, and more collagenous fibers has become WHO grade I, the classical HPC subtype with high cell density as grade II, and variable amounts of mitoses and necrosis as grade III. The distinction is based on the level of mitoses, with less than 5 mitosing cells per 10 high-power fields defined as grade II, and five or more mitosing cells per ten high-power fields defined as grade III. These grades have been reported to correlate with clinical prognosis (7).

SFT/HPC did not demonstrate any specific imaging features. Radiological findings such as mixed high and low signal areas (yin-yang sign) on T2-weighted images, less dural tail sign unlike meningioma, less calcification, and bone destruction are reported as key points to consider for differentiation (4,8,9). The tumor often demonstrates marked enhancement with prominent flow voids on MRI due to its hypervascularity (10). However, there have been reports of cases that do not show such imaging features, and these often mimic various tumors, such as meningioma and schwannoma, in imaging findings. Case 1 presented with a dural tail sign and no yin-yang sign or flow void, which led to the preoperative diagnosis of meningioma. Case 2 demonstrated an irregular shape with flow void on T2WI MRI. Differences in these imaging features also affect intraoperative findings: in case 1, a meningioma was suspected due to the hardness of the tumor with an attachment to the dura; in case 2, a highly malignant tumor was suspected because it was easily hemorrhagic and partially adherent to the surrounding tissue. Intraoperative frozen section diagnosis showed that case 1 was a grade I meningioma and case 2 was a grade IV PNET-like tumor; however, the definitive histopathologic diagnosis was SFT/HPC in both cases because of STAT6 positivity. As shown above, it is difficult to predict the diagnosis of SFT/HPC.

The gold standard treatment for spinal SFT/HPC is total resection, if possible. Partial resection increases the recurrence rate, and pathologic grade is associated with local recurrence and distant metastasis rates (11). However, because of the low incidence of spinal cord SFT/HPCs, there have been no reports on the relationship between tumor grading and removal rate. According to the literature, SFTs that are currently equivalent to grade I are well circumscribed, smooth surfaced, partially or completely encapsulated, and described as firm and mostly solid (3). On the other hand, hemangiopericytoma, which is currently equivalent to grade II or III, sometimes infiltrates the nerve roots or invades the spinal cord (12,13). These differences in tumor characteristics determine the degree of surgical difficulty, especially in the craniocervical junction. To the best of our knowledge, there have been 12 cases of SFT/HPC occurring at the craniocervical junction, including our cases (6,12,14-19). Of these, 8 were grade I, and 4 were grade II or III, with an average age of 44 years (10–75 years); 7 were male and 5 were female. Clinical symptoms ranged from paralysis and sensory disturbances to headache and neck pain. The minimum follow-up period was 6 months, with a maximum of 7 years. In this series, there was only one case of classic HPC (grade II or III) had tumor recurrence (6), and none had metastasis. According to the surgical findings in the literature describing SFT/HPC grade I, detachment of the tumor and surrounding structures is easy, while for Grade II or III tumors, this is difficult to remove as the vertebral artery is involved or the tumor was adherent to the spinal cord (Table 1). As in our two cases, the higher the WHO grade, the more careful the surgical manipulation required to avoid damaging the surrounding vital structures and the higher the risk of residual tumor.

Conclusions

We encountered two targeted cases of SFT/HPC at the craniocervical junction. The more malignant the lesion, the more likely it is to progress to involve the surrounding vital tissues. SFT/HPC at the craniocervical junction with a higher WHO grade might have difficulty achieving gross total removal of the tumor, leading to poor prognosis.

Acknowledgments

Funding: This work was funded by Japan Society for the Promotion of Science, Grant-in-Aid for Early-Career Scientists 20K17962.

Footnote

Reporting Checklist: The authors have completed the CARE reporting checklist. Available at https://dx.doi.org/10.21037/jss-21-83

Peer Review File: Available at https://dx.doi.org/10.21037/jss-21-83

Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at https://dx.doi.org/10.21037/jss-21-83). The authors have no conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient for publication of this case report and accompanying images. A copy of the written consent is available for review by the editorial office of this journal.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.

References

1. Louis DN, Ohgaki H, Wiestler OD, et al. WHO Classification of Tumors of the Central Nervous System, 4th Edition, Revised Edition. IARC, Lyon 2016:249-51.
2. Alexiev BA, Finkelman BS, Streich L, et al. Solitary fibrous tumor of thoracic cavity, extra-thoracic sites and central nervous system: Clinicopathologic features and association with local recurrence and metastasis. Pathol Res Pract 2021;224:153531. [Crossref] [PubMed]
3. Bisceglia M, Galliani C, Giannatempo G, et al. Solitary fibrous tumor of the central nervous system: a 15-year literature survey of 220 cases (August 1996-July 2011). Adv Anat Pathol 2011;18:356-92. [Crossref] [PubMed]
4. Fargen KM, Opalach KJ, Wakefield D, et al. The central nervous system solitary fibrous tumor: a review of clinical, imaging and pathologic findings among all reported cases from 1996 to 2010. Clin Neurol Neurosurg 2011;113:703-10. [Crossref] [PubMed]
5. Betchen S, Schwartz A, Black C, et al. Intradural hemangiopericytoma of the lumbar spine: case report. Neurosurgery 2002;50:654-7. [PubMed]
6. Shirzadi A, Drazin D, Gates M, et al. Surgical management of primary spinal hemangiopericytomas: an institutional case series and review of the literature. Eur Spine J 2013;22:S450-9. [Crossref] [PubMed]
7. Sung KS, Moon JH, Kim EH, et al. Solitary fibrous tumor/hemangiopericytoma: treatment results based on the 2016 WHO classification. J Neurosurg 2018; [Epub ahead of print]. [PubMed]
8. Liu HG, Yang AC, Chen N, et al. Hemangiopericytomas in the spine: clinical features, classification, treatment, and long-term follow-up in 26 patients. Neurosurgery 2013;72:16-24; discussion 24. [Crossref] [PubMed]
9. Wang XQ, Zhou Q, Li ST, et al. Solitary fibrous tumors of the central nervous system: clinical features and imaging findings in 22 patients. J Comput Assist Tomogr 2013;37:658-65. [Crossref] [PubMed]
10. Fitzpatrick D, Mahajan J, Lewkowitz M, et al. Intradural hemangiopericytoma of the lumbar spine: a rare entity. AJNR Am J Neuroradiol 2009;30:152-4. [Crossref] [PubMed]
11. Albert GW, Gokden M. Solitary fibrous tumors of the spine: a pediatric case report with a comprehensive review of the literature. J Neurosurg Pediatr 2017;19:339-48. [Crossref] [PubMed]
12. Wei D, Ma M, Li H. Invasive Solitary Fibrous Tumor/Hemangiopericytoma of the Filum Terminale. World Neurosurg 2020;139:318-21. [Crossref] [PubMed]
13. Moscovici S, Ramirez-DeNoriega F, Fellig Y, et al. Intradural extramedullary hemangiopericytoma of the thoracic spine infiltrating a nerve root: a case report and literature review. Spine (Phila Pa 1976) 2011;36:E1534-9. [Crossref] [PubMed]
14. Brunori A, Cerasoli S, Donati R, et al. Solitary fibrous tumor of the meninges: two new cases and review of the literature. Surg Neurol 1999;51:636-40. [Crossref] [PubMed]
15. Endo K, Komagata M, Ikegami H, et al. Dumbbell-type solitary fibrous tumor in the cervical spine. J Orthop Sci 2003;8:428-31. [Crossref] [PubMed]
16. Obara Y, Matsumoto M, Chiba K, et al. Solitary cervical fibrous tumor. Case illustration. J Neurosurg 2003;98:111. [PubMed]
17. Hirakawa A, Miyamoto K, Hosoe H, et al. Solitary fibrous tumor in the occipitocervical region: a case report. Spine (Phila Pa 1976) 2004;29:E547-50. [Crossref] [PubMed]
18. Tsutsumi N, Kojima Y, Nishida K, et al. Surgical treatment for recurrent solitary fibrous tumor invading atlas. Head Neck 2014;36:E121-4. [Crossref] [PubMed]
19. Zaldivar-Jolissaint JF, Mascott C, Gugliotta M, et al. Extensive bone remodeling from a solitary fibrous tumor of the cervical spine. Spine J 2016;16:e699-700. [Crossref] [PubMed]
