Clinical and radiologic outcomes and complications of unilateral S2AI screw fixation in adult spinal deformity surgery: a retrospective cohort study

Introduction

Background

Adult spinal deformity (ASD) is a multifactorial condition affecting both the sagittal and coronal balance of the spine. Achieving optimal global alignment and ensuring successful long-term clinical outcomes in ASD patients often requires rigid lumbosacral fixation during corrective fusion surgeries with extended constructs (1,2). Previous studies have also reported a protective effect against pseudarthrosis at the L5-S1 level when lumbopelvic fixation is used in these long constructs (3,4). Traditionally, S1 screw instrumentation has been employed for spinal fusion in ASD surgery. However, the strain on screws, particularly during flexion, can lead to complications (3,5).

To address these challenges, various lumbopelvic fixation techniques have evolved over the years, including the classic Galveston, iliac screw, sacral-alar-iliac (S2AI) screw and stacked S2AI screw techniques. These methods aim to enhance biomechanics and stability in long-segment fixation, reduce pseudarthrosis, achieve and maintain the correction of spinal deformity, and prevent sacral fractures below S1 screws.

However, traditional iliac screw fixation, which involves placing screws at the posterior superior iliac spine, has drawbacks, such as the need for lateral offset connectors to the rod, increased soft tissue dissection, and a higher risk of screw prominence, potentially leading to wound complications (3,6-8).

The S2AI screw, positioned more medially and aligned with the S1 screws, offers comparable biomechanical properties to the iliac screw but with fewer complications related to screw prominence (7,8). Nevertheless, Ha et al. found that 9.6% of patients experienced screw-related pain because trajectory passing through the normal sacroiliac (SI) joint, and 3.4% required screw removal within two years of follow-up (9). This suggests that while S2AI screws have advantages, they still present complications, especially with bilateral S2AI screws that pass through both SI joints.

Unilateral S2AI screw fixation emerges as a potential solution, aiming to minimize complications compared to bilateral fixation. Studies on unilateral lumbopelvic fixation are limited: Tomlinson et al. found no significant biomechanical difference in porcine spines (10), Nazemi et al. reported adequate fixation efficacy and low complication rates (11), and Saigal et al. observed comparable complication rates between unilateral and bilateral fixation (12).

Rationale and knowledge gap

Currently, there is no clear recommendation for identifying candidates suitable for unilateral S2AI screw fixation. Cho et al. reported risk factors for lumbopelvic fixation failure after long-level fusion in ASD, including previous lumbar surgery, greater pelvic incidence (PI), poor restoration of lumbar lordosis (LL), and sagittal imbalance (13). Martin et al. also identified risk factors for catastrophic failure of lumbopelvic fixation, particularly after extensive correction in ASD surgery (14).

Objective

We hypothesize that in cases of mild to moderate deformity, as defined by the Scoliosis Research Society (SRS)-Schwab classification with a sagittal modifier of only one plus, no prior surgery, average PI and flexible deformity, unilateral S2AI screw fixation may be sufficient for lumbopelvic fixation (15). We present this article in accordance with the STROBE reporting checklist (available at https://jss.amegroups.com/article/view/10.21037/jss-24-172/rc).

Methods

Study design and patient selection

Eighty consecutive patients with mild to moderate degree of sagittal deformity, as classified by SRS classification, were retrospectively reviewed. Included patients had a mismatch between PI and LL (PI-LL mismatch) of no more than 20°, a sagittal vertical axis (SVA) of no more than 9 cm, and a pelvic tilt (PT) of no more than 30°. Each patient underwent ASD surgery with unilateral S2AI screw placement between December 2016 and June 2022, performed by a single surgeon at Thammasat University Hospital, Thailand. Inclusion criteria were ASD surgery with unilateral S2AI screw fixation, long posterior spinal fusion (≥6 levels) from the lower thoracic region to the pelvis, age ≥50 years, and a minimum 2-year follow-up. Deformity correction was planned according to the age-adjusted alignment concept (16). Deformity correction involved the interbody fusion technique and low-grade Schwab osteotomy without using the three-column osteotomy technique. In cases with coronal imbalance, the S2AI screw was inserted on the same side as the truncal shift, for the same reason as the kickstand rod technique (17). In cases without coronal imbalance, the S2AI screw side was decided by the surgeon’s preference (Figure 1). Patients with incomplete radiographic data were excluded. This retrospective cohort study was conducted in compliance of the Declaration of Helsinki and its subsequent amendments. The Human Ethics Committee of Thammasat University approved this study (approval No. MTU-EC-OT-0-296/67). The inform consent was not performed due to the nature of retrospective study.

Figure 1 Preoperative (A,B) and 1-year postoperative (C,D) images show an improvement in lumbar lordosis from 20.2° to 31°, in SVA from 15.8 to 6 cm, and in PI-LL from 29° to 19°. LL, lumbar lordosis; PI, pelvic incidence; PI-LL mismatch, mismatch between PI and LL; SVA, sagittal vertical axis.

Radiographic measurements

Preoperative and postoperative measurements of PI, PT, sacral slope (SS), LL, thoracic kyphosis (TK), T1 pelvic angle (TPA), SVA, and PI-LL mismatch were obtained from standing full-length lateral radiographs at various postoperative intervals (immediate, 2-week, 3-month, 6-month, 1-year, and 2-year). These measurements were performed by a fellowship-trained spine surgeon and two orthopedic residents using a Picture Archiving and Community System (PACS). Fusion of L5/S1 was assessed at the 2-year postoperative period with plain anteroposterior (AP) and lateral radiographs. For cases involving L5/S1 transforaminal lumbar interbody fusion (TLIF), the fusion status was classified as grade 2 according to the method described by Patil et al. (18). For cases with posterolateral fusion (PLF), the segment was marked as fused if there was evidence of fusion mass and stability in position.

Complications

The recorded postoperative complications within two years that were reviewed included reoperation rates, screw loosening, screw fracture, rod breakage, S2AI screw-related pain, infection, and proximal junctional kyphosis (PJK). The diagnosis of S2AI screw-related pain was conducted through clinical evaluation, requiring at least three positive provocative tests (19), without the use of diagnostic injections or additional radiographic tests such as computed tomography (CT) or magnetic resonance imaging (MRI) studies.

Statistical analysis

Statistical analysis was conducted using Stata version 16 (Stata Corp., College Station, TX, USA). Associations with P values less than 0.05 were considered statistically significant. Student’s t-test and chi-square test were applied for continuous and categorical variables, respectively. Radiographic analysis was used to compare pre- and postoperative measurements.

Results

A total of 80 consecutive patients were included (Table 1). The mean [± standard deviation (SD)] age was 68.7±6.7 years, and 72 (90%) were women. The median [interquartile range (IQR)] fusion level was 9 [8, 9]. TLIF was performed in 70% of patients, with a median [IQR] of 1 [1, 2] levels. Oblique lumbar interbody fusion was performed in 15% of patients, with a median [IQR] of 2 [2, 2] levels.

Mean (± SD) preoperative values were as follows: PI, 51.1°±11.4°; SS, 21.6°±11.4°; PT, 29.3°±11.3°; SVA, 7.8±5.5 cm; LL, 21.8°±16.7°; PI-LL, 29.3°±17.3°; TK, 16.8°±12.1°; and TPA, 31.9°±12.3° (Table 2). The immediate postoperative parameters, including SS, PT, LL, PI-LL, TK and TPA, showed statistically significant improvement at all follow-up times compared to the preoperative radiographs. Mean (± SD) postoperative values were as follows: SS, 25.6°±10.8°; PT, 24.1°±8.7°; SVA, 4.0±5.0 cm; LL, 34.2°±12.1°; PI-LL, 16.6°±10.7°; TK, 23.0°±10.0°; and TPA, 27.3°±10.5°.

The 2-year postoperative fusion rate was 95% (76/80) (Table 3). The overall complication rate was 21% (17 patients), including four cases of S1 screw loosening, two cases of PJK, six cases of rod breakage (Figure 2) and three cases of S2AI screw-related pain. Two re-operations (3%) were performed due to rod breakage (Figure 3), resulting from loss of reduction following the fracture.

Figure 2 Radiograph of a 70-year-old male. (A) AP radiograph; (B) lateral standing radiograph; (C,D) postoperative standing radiographs show correction of LL from 9° (PI-LL 39) to 36° (PI-LL 12) lordosis; (E,F) seven-month postoperative standing radiograph: AP radiograph showing broken rod (black arrow), lateral radiograph showing LL decreased to 27° (PI-LL 19). AP, anterolateral; LL, lumbar lordosis; PI, pelvic incidence; PI-LL mismatch, mismatch between PI and LL; SVA, sagittal vertical axis.

Figure 3 Radiograph of a 58-year-old female. (A) AP radiograph, (B) lateral standing radiograph. Postoperative standing radiographs show correction of LL from 21° (PI-LL 47) to 36° (PI-LL 32) lordosis. Ten-month postoperative standing radiographs (C,D): AP radiograph showing broken rod on both sides (black arrows); lateral radiograph showing LL decreased to 3° (PI-LL 65). (E,F) Radiographs after revision surgery, showing a large amount of correction with LL improved to 35° (PI-LL 33). AP, anterolateral; LL, lumbar lordosis; PI, pelvic incidence; PI-LL mismatch, mismatch between PI and LL; SVA, sagittal vertical axis.

Discussion

The technique of lumbopelvic fixation has evolved significantly over the years, with bilateral S2AI screws representing one of the latest advancements. These screws aim to reduce pain and complications compared to traditional iliac screws by eliminating the need for lateral offset connectors, decreasing soft tissue dissection, and minimizing the risk of screw prominence (3,5-7). The introduction of S2AI screws sought to address these issues by providing comparable biomechanical properties while reducing complications related to screw prominence. However, persistent challenges, including screw-related pain, prompted further exploration of alternative techniques, leading to the consideration of unilateral S2AI screw fixation.

A study by Ha et al. reported persistent bilateral S2AI screw-related pain in approximately 9.6% of patients, with 3.4% requiring screw removal (9). In contrast, our study observed a lower incidence of S2AI screw-related pain, affecting only 4% of patients, none of whom required reoperation after initiating conservative treatment. Thus, we identified the potential benefits of unilateral S2AI screw fixation in resolving these complications in patients with mild to moderate sagittal deformity, flexible spines, no previous surgeries, and average PI. Our findings suggest that unilateral fixation may provide comparable outcomes with potentially less operative time.

We found that unilateral screw fixation resulted in a statistically significant improvement in radiographic parameters, with changes in SVA and LL comparable to those reported in existing studies (10,11).

Regarding L5S1 fusion, a previous study by Nazemi et al. compared radiographic and clinical complications of patients who underwent thoracolumbar fusion using either S2AI screws or unilateral iliac bolt fixation. The study reported a pseudarthrosis rate of 10% (1/10) in the S2AI screw group and 21% (4/19) in the unilateral iliac bolt fixation group (11). These findings are comparable to our study, which reported a 95% fusion rate and a 5% pseudarthrosis rate. When compared to the results of spinopelvic fixation with unilateral and bilateral iliac screws reported by Saigal et al., the pseudarthrosis rate in our study was lower than both the unilateral group [13% (3/46)] and the bilateral group [19% (5/26)] (12). However, a limitation of both Nazemi’s and Saigal’s studies was the lack of clear patient selection criteria, whereas in our study, nearly 70% of cases involved L5S1 interbody fusion.

In our study, the reoperation rate was 3%, which is similar to a study by Martin et al. where 5% of patients (6/125) required reoperation due to acute failure of S2AI screws within 6 weeks postoperatively (20). Martin et al. also found that changes in LL were statistically significantly greater in the failure group compared to the non-failure group. Additionally, Ha et al. reported that 9.6% of patients experienced S2AI screw-related pain, and 3.4% required a second operation for screw removal (9). In contrast, our study had no cases of reoperation due to screw-related pain. However, two patients required re-operative surgery due to loss of reduction following rod fracture, which resulted in sagittal imbalance and intolerable back pain.

The observed complication rate of 13% is consistent with rates reported for bilateral S2AI screws in previous studies (9,21). This suggests that unilateral S2AI fixation may offer comparable outcomes with less operative time and blood loss.

One significant aspect of our study is the proposed patient categorization for appropriate lumbopelvic fixation selection. This framework focuses on an average PI population with mild to moderate degrees of sagittal deformity and flexible splines, without prior surgeries, and yields promising outcomes. Based on our findings, we recommend selecting patients for unilateral lumbopelvic fixation based on the following criteria: (I) mild to moderate sagittal deformities, as classified by the SRS classification; (II) a flexible spine that does not require three-column osteotomy; and (III) no prior spinal surgeries. For patients with mild deformities who do not have global imbalance but require multiple-level fusions, lumbopelvic fixation may not be necessary. We recommend bilateral lumbopelvic fixation for patients with severe sagittal deformities, rigid spines requiring three-column osteotomy, or those with a history of previous spinal surgery. Additionally, patients with severe coronal and sagittal deformities may require multiple lumbopelvic fixations to achieve optimal alignment and stability.

The proposed patient categorization introduces a valuable framework for surgical decision-making in ASD cases. By aligning the selection of lumbopelvic fixation methods with specific patient characteristics, surgeons can tailor interventions to optimize outcomes. This patient-centric approach is particularly pertinent in the era of precision medicine, where treatment strategies are increasingly individualized. Future studies should explore the applicability and generalizability of this categorization in diverse patient populations and clinical settings.

Our study has several limitations. The retrospective nature of the study and the limited sample size of 80 patients may affect the generalizability of the findings. Additionally, the 2-year follow-up period may not capture long-term complications or outcomes. Limitations in data records and investigative methods also reduce the precision in determining outcomes such as fusion rate or pseudarthrosis, which are more accurately assessed with CT scans rather than plain radiographs. Future research would benefit from larger, prospective studies with longer follow-up durations and more precise investigative methods to validate our findings and further explore patient selection.

Comparative effectiveness analysis with other lumbopelvic fixation techniques, such as iliac screws and bilateral S2AI screws, is crucial for providing a comprehensive understanding of the strengths and limitations of each method. This study contributes to the existing literature by highlighting the feasibility and efficacy of unilateral S2AI screw fixation. Future research should involve direct comparisons with other techniques to guide surgeons in selecting the most appropriate fixation method based on patient-specific factors and surgical goals. Advancements in imaging and navigation technologies offer additional opportunities to enhance the precision and safety of spinal surgeries. Integrating these technologies into the planning and execution of unilateral S2AI screw fixation may further optimize outcomes. Exploring the role of navigation systems, robotics and intraoperative imaging in improving accuracy and reducing complications is an important avenue for future research.

Conclusions

In conclusion, unilateral S2AI screws are a viable technique for lumbopelvic fixation in patients with mild to moderate deformity, flexible spines, no previous surgeries, and average PI. This approach effectively corrects and maintains alignment, improves clinical outcomes, and has a complication rate comparable to that of bilateral S2AI fixation. The proposed patient categorization serves as a practical guide for selecting the appropriate lumbopelvic fixation method based on individual patient characteristics.
